22'Wx24'Lx12'H Two Car Instant Garage Peak Style
This 22' x 24' two car portable garage gives you room to park two standard-size vehicles side by side under a peak roof that tops out at 12 feet. The extra height also makes it a practical workshop. With a door at each end, you can pull in one side and drive out the other.
Why it’s worth it
Steel frame: 2-3/8" galvanized steel tubing, with seven arches set 48" apart and wind bracing at all four corners.
Weather-ready cover: 10 oz. fabric-backed poly, UV treated and fire retardant. Both the main cover and the doors meet CPAI-84 Section 5.
Drive-thru doors: each end gets a 20' x 6'6" triple-zipper door with bottom pockets, and a roll-up door kit is included.
Simple assembly: every part arrives cut and pre-drilled, and the bolt-together hardware comes with a quick-assembly wrench. The manufacturer’s average install time is about 2 hours.
Included
10 oz. UV Treatment Cover
2 Triple Zipper Doors- 20’W x 6’6″H
14 Cable Earth Anchor Kit
2-3/8″ Galvanized Steel Frame
Roll-Up Door Kit for Front Door Included
No reviews
Free Shipping
Authorized Dealer
Lowest Prices Guaranteed
Additional Information
Good to know
The 12' measurement is at the peak. The end doors open to 6'6", so check your tallest vehicle, roof rack included, before you order. Pick a level spot with some working room beyond the 22' x 24' footprint. The included cable anchors are meant for ground installs; on concrete or asphalt you’ll need anchors made for that surface. It ships by motor freight in six boxes totaling 789 lbs, so have a second person around on delivery day.
Exclusive Features
Heavy Duty Galvanized Finish on All Steel Frame Components for Maximum Strength & Long Life
Easy Bolt Together Design – All Pre-drilled & Cut
Wind Brace Support on all 4 corners
Two (2) Triple Zipper Doors with Bottom Pockets
One (1) complete Roll-up Door Kit
Protective Plastic Tube End Caps – All Open Ends
Standard Thread Plated Hardware Kit with Retaining Nuts & Protective SS Washers
Quick Assembly Wrench included
Heavy Duty Poly Rope for Main Cover Tie Down
Heavy Duty Grommets on Cover & Doors
Six Box Shipment – easily unloaded and transported
Average Install time – 2 hours
Standard Specifications
Product Size 22’ Wide x 24’ Long x 12’ High
Arches Seven (7) on 48” Spacing 2-3/8” diameter frame members
Standard End Door Size 20’ Width X 6’6″ Height
Available Colors Outer Colors: Green, Gray or Tan
All Interiors: Bright White Only
Shipping Weight 789 lbs shipped in Six (6) boxes Shipped via Motor Freight
Pallet Dimensions 40″W x 89″L x 31″
Main Cover UV Protected Fabric Backed Poly Material 10 oz. Weight
Fire Retardant Standard Main Cover & Doors meet CPAI -84 Section 5
Box Dimensions
Box 1: 60″ Long x 15″ Wide x 5″ High
Box 2: 88″ Long x 11″ Wide x 5″ High
Box 3: 50″ Long x 18″ Wide x 10″ High
Box 4: 65″ Long x 26″ Wide x 9″ High
Box 5: 60″ Long x 15″ Wide x 5″ High
Box 6: 67″ Long x 23″ Wide x 9″ High
Anchors Fourteen(14) 36″Anchors with U-Bolts & Drive Rod
